This study was performed to determine the long-term maxillomandibular positional stability after bimaxillary surgery with SFA to correct the skeletal class III deformity, which required a clockwise rotation of the maxillomandibular complex. One of the most important purposes of orthognathic surgery is to improve facial balance and esthetics. By SFA, orthognathic patients can improve their facial balance from the beginning of the surgico-orthodontic treatment and take advantage of shortening the total treatment time. In this study, all patients in the SFA group were satisfied with their early changes in facial esthetics and shortened treatment duration.
Originally, SFA was proposed for only mild to moderate skeletal class III deformities. However, the scope of SFA has recently expanded to bimaxillary surgery , including treatment of asymmetrical skeletal class III deformities . In our study, the number of patients with apparent facial asymmetry showing a difference of 3 mm or more in the amount of mandibular setback on each side was four in the SFA group and nine in the CA group. We excluded patients who showed severe anterior open bite or severe mandibular asymmetry in the SFA group. However, statistically, there was no bias in the facial features between the SFA and CA groups.
All operations were bimaxillary procedures accompanied by a posterior impaction or unilateral impaction of the maxillary segment. Therefore, we considered a forward movement of the mandible and inferior movement of the maxilla as the direction of relapse. The amount of mean setback movement of the mandible was 9.3 mm in the SFA group and 9.5 mm in the CA group. In addition, the amount of mean superior movement of the PNS was 3.0 mm in the SFA group and 1.7 mm in the CA group, which had no significant difference statistically. Many patients in both groups underwent genioplasty, which did not affect the position of point B in our surgical design. Osteofixation was achieved by absorbable PLLA, which demonstrated predictable skeletal stability compared to that of titanium plating systems . Immediately after the orthognathic procedure, we injected routine dosage of botulinum toxin into the masseter muscles bilaterally to decrease the muscular force .
In the surgical change, point B was significantly moved superiorly in the CA group but not in the SFA group, although maxillary impaction had been performed. This is because the vertical dimension of occlusion in the SFA group, which means the superior-inferior relationship of the maxilla and the mandible when the teeth are occluded in surgical stent, was increased to avoid occlusal interference due to unstable surgical occlusion. For the same reason, the occlusal plane angle significantly increased only in the CA group. Other surgical changes in this study were based on the maxillomandibular segmental movements from the surgical plan of grossly maxillomandibular clockwise rotation.
As the increased vertical dimension of occlusion in the SFA group decreased during the period of postoperative orthodontic treatment, the mandible was moved anteriorly as a result of the counterclockwise rotation. Therefore, at 6 months postoperatively, point B was moved to a horizontally anterior position only in the SFA group, indicating a short-term relapse. Actual horizontal changes of point B were 1.96 ± 2.09 mm in the SFA group and 1.03 ± 2.64 mm in the CA group. In contrast, in the CA group, SNB was increased, and ANB was decreased, which also suggests that point B was moved anteriorly. Actual changes of SNB were 1.81 ± 2.63° in the SFA group and 1.30 ± 1.24° in the CA group, which can be considered in the normal range of relapse in BSSRO and mandibular setback surgery . However, most parameters related to the maxillary change had no significance in either group, except that it was significantly moved superiorly only in the CA group. The CA group had relatively stable occlusion with almost full-size orthodontic archwires after surgery. Therefore, the application of class III elastics during postoperative orthodontic treatment might be more easily transferred to the maxilla, resulting in the displacement of point A.
Mah et al. reported greater horizontal and vertical relapse at the time point of postoperative 1 year or debonding in the surgery-first orthognathic approach for skeletal class III correction . They suggested that the postoperative counterclockwise rotation of the mandible in the surgery-first orthognathic approach causes relapse. However, Park et al. reported no significant differences in terms of postoperative stability at 6 months after bimaxillary surgery for skeletal class III malocclusion, either with or without preoperative orthodontic treatment . They found that the similar relapse rates between both groups were due to their standardized rigid inclusion criteria for surgery-first bimaxillary surgery.
In another clinical study, Han et al. reported additional horizontal relapse of the mandible until the time point of debonding (16.6 months after surgery) after mandibular setback surgery in an SFA . Therefore, they suggested that it is necessary to consider mandibular forward movement from the increase in the vertical dimension of surgical occlusion and additional relapse in the SFA. However, in this study, all measuring parameters related to long-term relapse did not show any significant change in the SFA group at the time point of postoperative 2 years. In our practice, the average debonding time was 14.7 months after surgery in the SFA group. Therefore, we believe that the unstable surgical occlusion in the SFA group stabilized within 6 months postoperatively. Taken together, after 6 months postoperatively, there was no additional skeletal relapse in our surgery-first protocol.
The key is how the temporary instability of the surgically created occlusion is resolved in postsurgical treatment. We successfully overcame unstable surgical occlusion in the SFA group by stable osteofixation at the osteotomy site and application of our protocol during orthodontic treatment. At initial diagnosis, we applied the SFA using 3D-CBCT (Alphard VEGA, ASAHI ROENTGEN, Japan) virtual imaging and simulation surgery to predict accurate postsurgical tooth alignment . To cover the unstable surgical occlusion, we initiated orthodontic movements after 1 month of stabilization. Therefore, we can use the active period of surgery-induced, regionally accelerated phenomenon, which is known to be active 3–4 months after surgery . We maintained a consistent skeletal relationship using effective interocclusal elastics. Lastly, the decreased masseter muscle thickness from the injection of the botulinum toxin  seems to mitigate the undesirable force from the masseter muscle, which acts in the relapse tendency.
One of the advantages of SFA is that it shortens the duration of surgico-orthodontic treatment. This study demonstrated that the average of total treatment time in the CA group was 26.0 months (range, 12‑42 months). In contrast, the average of total treatment time in the SFA group was 15.1 months (range, 9‑24 months). From a clinical point of view, extraction of the maxillary premolars and closing the extraction sites for orthodontic purposes might be the most influential factor on the total treatment time. In this study, the number of orthodontic cases with premolar extraction was two out of eight in the SFA group and 14 out of 20 in the CA group. In conventional treatment planning, severe crowding of the anterior teeth is ruled out for SFA. Therefore, the percentage of tooth extraction was higher in the CA group than in the SFA group, which affected the total treatment time. A prospective study regarding the treatment period for skeletal class III dentofacial deformities reported that the average of total treatment period of the SFA was shorter (14.6 months) than the CA (22.0 months). Thus, SFA dramatically reduced treatment time . Other studies have suggested that the observed reduction in total treatment duration is related to more efficient orthodontic protocols, such as skeletal anchorage or palatal arch expansion [24, 25].
In summary, this study demonstrated the tendency of short-term relapse in the mandibular position in the correction of skeletal III deformity regardless of preoperative orthodontic preparation. In particular, the actual change in point B was greater in the SFA group than in the CA group due to unstable surgical occlusion. However, this temporary instability was easily resolved within 6 months after the operation, without damaging long-term mandibular stability. In addition, the maxillary position remained stable throughout the course of surgico-orthodontic treatment. However, the limitation of this study is the reliability of the statistics due to the small sample size of the SFA group. And the data was analyzed by 2-dimensional measurements only, not the 3-dimensional ones. Therefore, a prospectively designed study with larger sample size is needed. Intimate cooperation between the orthognathic surgeon and the orthodontist is crucial to achieving a successful result in SFA due to the absence of preoperative occlusal preparation.
